LG 75TR3DJ 75" Class TR3DJ Series 4K UHD IPS Interactive Digital Board (75TR3DJ-B)
LG 75TR3DJ 75" Class TR3DJ Series 4K UHD IPS Interactive Digital Board (75TR3DJ-B)
LG 75TR3DJ 75" Class TR3DJ Series 4K UHD IPS Interactive Digital Board (75TR3DJ-B)
Brand
:
LG
Model
:
75TR3DJ
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
| Technical Parameter | Industrial Specification |
| Brand & Model | LG 75TR3DJ (75TR3DJ-B) |
| Screen Size & Panel Technology | 75-inch In-Plane Switching (IPS) Panel |
| Native Resolution | 3840 x 2160 (4K Ultra HD / 2160p) |
| Aspect Ratio | 16:9 |
| Display Brightness | 390 cd/m² (Nits) Without Protection Glass / 350 cd/m² With Glass |
| Viewing Angles (H / V) | 178° / 178° Ultra-Wide Viewing Angle |
| Contrast Ratio | 1200:1 (Dynamic CR: 1,000,000:1) |
| Touch Technology Type | Advanced Infrared (IR) Sensing Frame |
| Simultaneous Touch Points | Up to 20 Points of Multi-Touch (Max 10 Points Writing) |
| Touch Response / Min Object | ≤ 10 ms / Ø 3 mm |
| Protection Glass Features | 4.0T (Thickness) Tempered Glass, Anti-Glare (Haze 8%-12%) |
| Operation Duty Cycle | 16 Hours / 7 Days Continuous Commercial Use |
| Smart Operating Platform | Android 9.0 (Embedded Operating System) |
| Internal Processing Core | Quad-Core CPU, Mali-G51 MP4 GPU |
| Memory & Storage | 3 GB RAM | 32 GB eMMC Internal Flash Storage |
| Connectivity (Input) | 3 x HDMI, 1 x RGB (VGA), 1 x Audio In, 4 x USB 2.0/3.0 (Type-A) |
| Connectivity (Output) | 1 x HDMI Out, 1 x Audio Out, 1 x Optical Out |
| Touch Interface Routing | 2 x USB Type-B Upstream Ports |
| External Device Control | RS232C In, RJ45 (LAN) In |
| Wireless Connectivity | Built-in Dual-Band Wi-Fi (802.11 a/b/g/n/ac) & Bluetooth |
| Integrated Audio Systems | Built-in Dual Speakers (12W + 12W Stereo) |
| Bezel Width | Top/Left/Right: 17.7 mm, Bottom: 45.7 mm |
| Physical Dimensions (W x H x D) | 1710 mm x 1020 mm x 86 mm (Without Wall Mount) |
| Net Product Weight | 53.0 kg |
| VESA Mount Standards | 800 mm x 400 mm |
| Technical Parameter | Industrial Specification |
| Brand & Model | LG 75TR3DJ (75TR3DJ-B) |
| Screen Size & Panel Technology | 75-inch In-Plane Switching (IPS) Panel |
| Native Resolution | 3840 x 2160 (4K Ultra HD / 2160p) |
| Aspect Ratio | 16:9 |
| Display Brightness | 390 cd/m² (Nits) Without Protection Glass / 350 cd/m² With Glass |
| Viewing Angles (H / V) | 178° / 178° Ultra-Wide Viewing Angle |
| Contrast Ratio | 1200:1 (Dynamic CR: 1,000,000:1) |
| Touch Technology Type | Advanced Infrared (IR) Sensing Frame |
| Simultaneous Touch Points | Up to 20 Points of Multi-Touch (Max 10 Points Writing) |
| Touch Response / Min Object | ≤ 10 ms / Ø 3 mm |
| Protection Glass Features | 4.0T (Thickness) Tempered Glass, Anti-Glare (Haze 8%-12%) |
| Operation Duty Cycle | 16 Hours / 7 Days Continuous Commercial Use |
| Smart Operating Platform | Android 9.0 (Embedded Operating System) |
| Internal Processing Core | Quad-Core CPU, Mali-G51 MP4 GPU |
| Memory & Storage | 3 GB RAM | 32 GB eMMC Internal Flash Storage |
| Connectivity (Input) | 3 x HDMI, 1 x RGB (VGA), 1 x Audio In, 4 x USB 2.0/3.0 (Type-A) |
| Connectivity (Output) | 1 x HDMI Out, 1 x Audio Out, 1 x Optical Out |
| Touch Interface Routing | 2 x USB Type-B Upstream Ports |
| External Device Control | RS232C In, RJ45 (LAN) In |
| Wireless Connectivity | Built-in Dual-Band Wi-Fi (802.11 a/b/g/n/ac) & Bluetooth |
| Integrated Audio Systems | Built-in Dual Speakers (12W + 12W Stereo) |
| Bezel Width | Top/Left/Right: 17.7 mm, Bottom: 45.7 mm |
| Physical Dimensions (W x H x D) | 1710 mm x 1020 mm x 86 mm (Without Wall Mount) |
| Net Product Weight | 53.0 kg |
| VESA Mount Standards | 800 mm x 400 mm |
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
Book a call
Yes, when sourcing your display through Trianze Tech in Dubai or Abu Dhabi, you can customize your installation kit. We supply heavy-duty fixed wall mounts, articulating brackets, and premium mobile trolley stands to suit your corporate room configuration, backed by a professional, local on-site engineering team.
Thanks to the built-in Android 9.0 architecture and a powerful internal quad-core processor, the display can access its native web browser, launch media players, and open presentations or MS Office files directly from internal flash memory or external USB drives without requiring an external laptop or PC.
The physical HDMI Output port acts as an active hardware loop-through. This allows you to clone anything currently shown on your 75" display—including live drawings, web pages, and annotations—and forward the video signal directly to an external recording system, a separate projector, or a secondary display monitor in a deep meeting room.
The screen surface is constructed from high-durability 4.0mm thick tempered glass featuring an advanced anti-glare treatment (8% to 12% haze rating). This specific layer scatters incoming glare from direct sunlight or bright office overhead LED arrays, preserving clear contrast and fine text lines without compromising color depth.
Yes, the interactive touch grid of the 75TR3DJ functions as an HID (Human Interface Device) compliant system over a simple USB connection. By running an HDMI cable for video and a standard USB Type-A to Type-B cable for touch data, your Windows 11 laptop will immediately recognize multi-touch gestures and ink inputs without installing manual device drivers.
