| Technical Parameter | Specification Details |
|---|---|
| Brand & Model | LG STB-6500 Pro:Centric Smart Set Top Box |
| Operating System | webOS 5.0 Smart Platform |
| Video Output Resolutions | 2160p (4K UHD), 1080p (Full HD), 720p (HD), 1366x768 |
| 4K Upscaling | Auto Upscales FHD Content from HDMI/USB to Ultra HD |
| Tuner Type | ATSC (Digital Terrestrial / Clear QAM Cable) |
| IP Streaming | Yes – Full IPTV Platform with IP Video Decoding |
| RF Tuning | Yes |
| Pro:Centric Platform | Pro:Centric Smart (webOS 5.0) + Pro:Centric Direct Support |
| Pro:Idiom DRM | Embedded Hardware/Software Pro:Idiom Decryption |
| HCAP Support | GEM / HTML5 |
| Pro:Centric webRTC | Yes (JavaScript only) |
| IP Return Path | Yes |
| Multicast / Unicast | Yes / Yes |
| HDMI Input | 2 x HDMI 2.0 (HDCP 2.2) |
| HDMI Output | 1 x HDMI 2.0 (HDCP 2.2) |
| USB Ports | 2 x USB 2.0 |
| LAN Port | 1 x RJ45 |
| Antenna / Cable Input | 1 x Coaxial RF Input |
| Optical Audio Output | 1 x Digital Optical (S/PDIF) |
| Audio Line Output | 1 x 3.5mm Jack |
| AV Input | 1 x 3.5mm Composite AV Jack |
| External IR Input | 1 x 3.5mm Jack |
| RS-232C TV Control | 1 x 3.5mm Jack |
| External RS-232C Control | 1 x 3.5mm Jack |
| MPI / MTI TV Control | 1 x RJ12 |
| External MPI Control | 1 x RJ12 |
| 60-Pin Expansion Interface | Yes (DOCSIS 3.0 Upgrade Option) |
| Wi-Fi | Yes (Built-in) |
| SoftAP | Yes (TV as Wireless Hotspot) |
| Screen Share / Miracast | Yes |
| Bluetooth Sound Sync | Yes (Android and iOS) |
| Smart Share (DLNA) | Yes |
| LG Connect App | Yes (LG TV Plus) |
| Gallery Mode | Yes |
| Web Browser | Yes (Updated Chromium) |
| Magic Remote Compatibility | Yes |
| SNMP / IP Remote Diagnostics | Yes |
| Simplink HDMI-CEC | Yes (v1.4 + CEC-HTNG) |
| USB Cloning | Yes |
| Wake on LAN | Yes |
| Energy Saving Mode | Yes |
| Power Supply | 120V AC, 50/60 Hz |
| Max Power Consumption | 60W |
| Typical Power Consumption | 14.1W (STB Only) / 44W (STB + Expansion Module) |
| Standby Power | Less than 1.5W |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | Less than 80% RH |
| Dimensions W x H x D | 233 x 180.5 x 29.8 mm |
| Weight Net | 0.72 kg |
| Warranty | 2-Year Limited Manufacturer Warranty |
| Included Accessories | AC Adapter, HDMI Cable, MPI Cable, RS-232C Cable, AV Adapter, Manual |
| Technical Parameter | Specification Details |
|---|---|
| Brand & Model | LG STB-6500 Pro:Centric Smart Set Top Box |
| Operating System | webOS 5.0 Smart Platform |
| Video Output Resolutions | 2160p (4K UHD), 1080p (Full HD), 720p (HD), 1366x768 |
| 4K Upscaling | Auto Upscales FHD Content from HDMI/USB to Ultra HD |
| Tuner Type | ATSC (Digital Terrestrial / Clear QAM Cable) |
| IP Streaming | Yes – Full IPTV Platform with IP Video Decoding |
| RF Tuning | Yes |
| Pro:Centric Platform | Pro:Centric Smart (webOS 5.0) + Pro:Centric Direct Support |
| Pro:Idiom DRM | Embedded Hardware/Software Pro:Idiom Decryption |
| HCAP Support | GEM / HTML5 |
| Pro:Centric webRTC | Yes (JavaScript only) |
| IP Return Path | Yes |
| Multicast / Unicast | Yes / Yes |
| HDMI Input | 2 x HDMI 2.0 (HDCP 2.2) |
| HDMI Output | 1 x HDMI 2.0 (HDCP 2.2) |
| USB Ports | 2 x USB 2.0 |
| LAN Port | 1 x RJ45 |
| Antenna / Cable Input | 1 x Coaxial RF Input |
| Optical Audio Output | 1 x Digital Optical (S/PDIF) |
| Audio Line Output | 1 x 3.5mm Jack |
| AV Input | 1 x 3.5mm Composite AV Jack |
| External IR Input | 1 x 3.5mm Jack |
| RS-232C TV Control | 1 x 3.5mm Jack |
| External RS-232C Control | 1 x 3.5mm Jack |
| MPI / MTI TV Control | 1 x RJ12 |
| External MPI Control | 1 x RJ12 |
| 60-Pin Expansion Interface | Yes (DOCSIS 3.0 Upgrade Option) |
| Wi-Fi | Yes (Built-in) |
| SoftAP | Yes (TV as Wireless Hotspot) |
| Screen Share / Miracast | Yes |
| Bluetooth Sound Sync | Yes (Android and iOS) |
| Smart Share (DLNA) | Yes |
| LG Connect App | Yes (LG TV Plus) |
| Gallery Mode | Yes |
| Web Browser | Yes (Updated Chromium) |
| Magic Remote Compatibility | Yes |
| SNMP / IP Remote Diagnostics | Yes |
| Simplink HDMI-CEC | Yes (v1.4 + CEC-HTNG) |
| USB Cloning | Yes |
| Wake on LAN | Yes |
| Energy Saving Mode | Yes |
| Power Supply | 120V AC, 50/60 Hz |
| Max Power Consumption | 60W |
| Typical Power Consumption | 14.1W (STB Only) / 44W (STB + Expansion Module) |
| Standby Power | Less than 1.5W |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | Less than 80% RH |
| Dimensions W x H x D | 233 x 180.5 x 29.8 mm |
| Weight Net | 0.72 kg |
| Warranty | 2-Year Limited Manufacturer Warranty |
| Included Accessories | AC Adapter, HDMI Cable, MPI Cable, RS-232C Cable, AV Adapter, Manual |
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
Book a call
The best place to buy the LG STB-6500 in the UAE is directly through Trianze Tech — the region's leading commercial AV integration and enterprise IT hardware distribution specialist. Trianze Tech supplies genuine, manufacturer-warranted LG hospitality hardware with fast local delivery across Dubai, Abu Dhabi, Sharjah, and the wider GCC. Unlike grey-market importers, purchasing through Trianze Tech guarantees authentic stock, full UAE regional warranty coverage, expert pre-sales consultation, professional installation support, and direct access to Trianze Tech's certified AV engineering team. Request a quote at trianzetech.com or contact the team via WhatsApp at +971 58 161 3661.
Pro:Centric Smart is the guest-facing application platform running on webOS 5.0, delivering the interactive hotel interface, IPTV channels, OTT apps, and customised room service menus visible on the in-room TV. Pro:Centric Direct (PCD) is the back-of-house hotel management and content management system (CMS) used by IT managers and property operators to remotely configure, update, and control all TVs and STB units across the property via an IP network — without entering guest rooms. Both platforms operate together: PCD manages what guests see, while Pro:Centric Smart delivers the guest experience itself.
Yes — this is one of the most valuable capabilities of the STB-6500 for hotel operators. The unit includes an embedded hardware and software Pro:Idiom DRM decryption engine, meaning it can deliver fully licensed, encrypted premium digital content to any compatible commercial television, including non-LG models and older displays that do not have Pro:Idiom natively built in. This protects the hotel's content licensing investment while allowing procurement teams to work with a wider range of television hardware across different room categories and price points — a significant operational and commercial advantage for large multi-brand hotel groups in the UAE.
The STB-6500 fully supports 4K Ultra HD (2160p) output when connected to a UHD-compatible commercial display. When the source signal — whether from HDMI input, USB media, or streamed IPTV content — is only Full HD (1080p), the STB-6500 automatically activates its built-in upscaling engine to enhance and output the content at Ultra HD resolution. This ensures that guests always receive the sharpest visual quality the connected display can deliver, regardless of the original source resolution — without any manual configuration required by hotel IT staff.
For guests, the STB-6500 offers SoftAP (the TV functions as a personal Wi-Fi hotspot), Miracast / WiDi screen sharing from smartphones and laptops, Bluetooth Sound Sync for wireless audio streaming, Smart Share (DLNA) for device content sharing, and the LG Connect (LG TV Plus) app as a smartphone remote. For hotel IT teams and system integrators, the unit provides RS-232C serial control, MPI/MTI television control (RJ12), RJ45 LAN with SNMP and IP remote diagnostics, VLAN ID support, Wake-on-LAN, USB cloning for mass deployment, Simplink HDMI-CEC v1.4, and a 60-pin expansion slot for optional DOCSIS 3.0 cable modem upgrades — making it one of the most integration-ready hospitality set top boxes available in the GCC market.
