• Display Configuration: The monitor features a 55-inch commercial-grade interactive screen built upon a high-performance Vertical Alignment (VA) panel with an advanced edge-lit LED backlight architecture.

• Touch Interface and Technology: It integrates high-speed, multi-point Projected Capacitive Touch technology using a micro-fine sensor matrix embedded behind the front glass.

• Resolution and Aspect Ratio: It operates at a native Ultra HD 4K resolution of $3840 \times 2160$ pixels mapped across a standard 16:9 cinematic display grid.

• Luminance and Visibility Performance: The display outputs 500 nits of typical panel brightness without glass, maintaining a high-visibility 400 nits of luminance with the active protective touch glass layer.

• Contrast Performance: It achieves a deep 4000:1 static contrast ratio alongside a Mega Dynamic Contrast Ratio to keep fine text details, maps, and UI elements perfectly sharp.

• Color Spectrum Engineering: The panel utilizes an advanced color engine with 10-bit processing depth, delivering a wide 92% DCI-P3 color gamut (CIE 1976 standard) to render over 1.07 billion distinct color variations.

• Response Speed: It features an 8ms grey-to-grey response time, providing fast interactive feedback during multi-touch gestures and high-speed content playback.

• Viewing Uniformity: It provides wide 178-degree horizontal and 178-degree vertical viewing angles, preventing off-axis color shifting or fading in public walk-ups.

• Anti-Glare Surface Diffusion: The durable front touch glass features a premium 25% non-glare haze diffusion coating that eliminates blinding reflections from overhead track lighting.

• Onboard Operating System: It runs the modern Samsung Smart Signage Platform (SSSP) powered by a native Tizen 6.5 Enterprise operating system with an upgradable web engine.

• Internal Hardware Processing: The processing architecture is driven by an integrated Cortex A72 1.7GHz quad-core CPU backed by 16GB of onboard high-speed flash storage.

• Duty Cycle and Reliability: The touchscreen is rated for continuous 24/7 mission-critical commercial operation, backed by industrial-grade internal cooling components.

• Environmental Shielding: The chassis features an IP5X certified dust-proof structural rating and a specialized internal conformal coating to protect against repeated public interaction.

• Physical Cabinet Geometry: It utilizes a sleek, symmetrical slim-design framework measuring 56.7 mm in overall profile depth with a premium non-glossy charcoal black structural frame.

• Mounting Integration: It natively supports both landscape and portrait mounting orientations, balanced perfectly by standard centered VESA 200 x 200 mm mounting holes.

• Core Video Interfaces: Input options include three HDMI 2.0 terminals supporting HDCP 2.2 and one DisplayPort 1.2 port.

• Data and Core Connectivity: It features built-in dual-band Wi-Fi (2.4/5.0GHz), Bluetooth, two USB 2.0 data ports, two dedicated Touch-Out USB Type-B upstream ports, and one RJ45 LAN connector.

• Network Command Control: It provides RS232C control input and output loops via standard mini-jacks, allowing full Multi-Display Control (MDC) remote management.

• Built-In Audio System: It includes an integrated 20W 2-channel professional speaker system comprising dual 10W built-in sound drivers.

Key Features

The Samsung QM55-BT represents a significant upgrade in slim-design interactive signage by embedding Projected Capacitive Touch technology directly into a sleek, commercial-grade 4K canvas. Running on Tizen 6.5 Enterprise OS, this panel operates as a true standalone interactive kiosk, utilizing Tizen Zero Config to let IT administrators remotely push apps and settings across multiple branch locations without local support. The premium 25% anti-glare haze coating ensures optimal readability under direct sunlight or office lights while lowering tracking friction for a smooth multi-touch experience. Fortified with an IP5X dust-proof rating and an innovative center IR receiver, the QM55-BT delivers continuous, high-performance retail and corporate engagement out of the box.
