| Technical Parameter | Specification / Feature Details |
| Model / MPN | QM55B-T (LH55QMBTBGCXZA / LH55QMBTBGCXUE) |
| Display Size & Type | 55-inch Commercial Direct-Lit LED / Advanced Touch-Integrated VA Panel |
| Touch Technology | High-Speed Projected Capacitive Touch (All-in-One Solution) |
| Native Resolution | Ultra HD 4K (3840 x 2160) | 16:9 Aspect Ratio Grid |
| Panel Brightness | 500 nits (Without Touch Glass) | 400 nits (Typical with Integrated Glass) |
| Contrast Ratio | 4000:1 (Static Layout Layer) | Mega Dynamic Contrast Ratio |
| Color Technology | High-Color 92% DCI-P3 Color Gamut Engine (CIE 1976 Layout) |
| Response Time | Fast 8ms G2G Structural Overdrive Tracking |
| Glass Haze / Non-Glare | 25% Premium Anti-Glare Layer with Smooth-Glide Coating |
| Onboard OS Platform | Samsung Smart Signage Platform (SSSP 10.0) | Tizen 6.5 Enterprise OS |
| Processor & Hardware | Cortex A72 1.7GHz Quad-Core CPU | 16GB High-Speed Flash Storage |
| Duty Cycle / Reliability | 24 Hours / 7 Days Continuous Heavy-Traffic Operation |
| Environmental Protection | IP5X Certified Dust-Proof Rating with Internal Conformal Coating Shield |
| Chassis Profile Depth | Ultra-Slim Interactive Profile (56.7 mm / 2.23 inches) |
| Orientation Options | Landscape & Portrait Configurations with Native Onboard Auto-Level |
| Video Input Interfaces | 3x HDMI 2.0 (HDCP 2.2), 1x DisplayPort 1.2 |
| Data & Core Connectivity | Wi-Fi Dual-Band, Bluetooth, 2x USB 2.0, 2x Touch-Out USB, 1x RJ45 LAN |
| Remote Management | RS232C In/Out, Custom Home UI Lockout, Tizen Zero Config |
| Mechanical Specs | Dimensions: 1253.8 x 734.6 x 56.7 mm | VESA: 200 x 200 mm | Weight: 26.9 kg |
| Technical Parameter | Specification / Feature Details |
| Model / MPN | QM55B-T (LH55QMBTBGCXZA / LH55QMBTBGCXUE) |
| Display Size & Type | 55-inch Commercial Direct-Lit LED / Advanced Touch-Integrated VA Panel |
| Touch Technology | High-Speed Projected Capacitive Touch (All-in-One Solution) |
| Native Resolution | Ultra HD 4K (3840 x 2160) | 16:9 Aspect Ratio Grid |
| Panel Brightness | 500 nits (Without Touch Glass) | 400 nits (Typical with Integrated Glass) |
| Contrast Ratio | 4000:1 (Static Layout Layer) | Mega Dynamic Contrast Ratio |
| Color Technology | High-Color 92% DCI-P3 Color Gamut Engine (CIE 1976 Layout) |
| Response Time | Fast 8ms G2G Structural Overdrive Tracking |
| Glass Haze / Non-Glare | 25% Premium Anti-Glare Layer with Smooth-Glide Coating |
| Onboard OS Platform | Samsung Smart Signage Platform (SSSP 10.0) | Tizen 6.5 Enterprise OS |
| Processor & Hardware | Cortex A72 1.7GHz Quad-Core CPU | 16GB High-Speed Flash Storage |
| Duty Cycle / Reliability | 24 Hours / 7 Days Continuous Heavy-Traffic Operation |
| Environmental Protection | IP5X Certified Dust-Proof Rating with Internal Conformal Coating Shield |
| Chassis Profile Depth | Ultra-Slim Interactive Profile (56.7 mm / 2.23 inches) |
| Orientation Options | Landscape & Portrait Configurations with Native Onboard Auto-Level |
| Video Input Interfaces | 3x HDMI 2.0 (HDCP 2.2), 1x DisplayPort 1.2 |
| Data & Core Connectivity | Wi-Fi Dual-Band, Bluetooth, 2x USB 2.0, 2x Touch-Out USB, 1x RJ45 LAN |
| Remote Management | RS232C In/Out, Custom Home UI Lockout, Tizen Zero Config |
| Mechanical Specs | Dimensions: 1253.8 x 734.6 x 56.7 mm | VESA: 200 x 200 mm | Weight: 26.9 kg |
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
Book a call
You can buy the genuine Samsung QM55B-T (Model: LH55QMBTBGCXZA) commercial display directly through TrianzeTech. Operating out of our head logistics and business office in Dubai, TrianzeTech handles procurement, verified local corporate AV deployments, and specialized cross-border pallet shipping to support commercial clients located in Cairo, Almaty, and the broader CIS region.
Procuring professional 55-inch interactive touch screens requires strict transport protocols to prevent panel flexing, glass fracturing, or damage to delicate capacitive touch sensors. By centralizing operations at our Dubai office, TrianzeTech manages localized quality checks, applies reinforced dual-pallet industrial crating, and handles targeted customs documentation. This reduces transit times and eliminates delivery complications for projects expanding into Cairo, Almaty, and the wider CIS territory.
Legacy IR touch displays rely on raised perimeter bezels housing optical sensors, which are easily disrupted by accumulated dust, moisture, or direct sunlight. The Samsung QM55B-T utilizes Projected Capacitive Touch (P-Cap), embedding a micro-fine grid of capacitive sensors directly behind the front glass overlay. This yields a completely flat, bezel-free design that is highly precise, supports faster multi-touch response loops, and remains unaffected by sunlight or dust.
Public interactive screens are exposed to oils from fingerprints and intense directional lighting inside retail stores, bank lobbies, or transit hubs. This can result in blinding light glare and friction buildup that hampers touch navigation. The QM55B-T solves this by utilizing a 25% non-glare haze surface treatment. This glass engineering scatters harsh overhead reflections to ensure high clarity while providing a low-friction, smooth-glide touch surface.
Using external mini-computers or unsecured android sticks behind public interactive displays creates open security vulnerabilities and configuration risks. The QM55B-T eliminates these threats by employing the SSSP 10.0 platform running Tizen 6.5 Enterprise OS, backed by multi-layered Samsung Knox security. Knox locks down the system firmware directory, shields active data streams, and isolates software environments, ensuring compliance with strict enterprise IT protocols.
Running a high-performance touch screen continuously generates static fields that pull floating dust and airborne micro-particles through cooling pathways. Over time, this dust buildup can insulate electronic components, leading to heat spikes and premature touch-layer degradation. The QM55B-T uses an IP5X certified dust-proof housing structure and internal conformal circuit coatings, which seals optical components to maximize operational lifespan in high-traffic public zones.
